FTW-300T Trailed Water Bowser

FTW-300T Trailed Water Bowser

Everything needed for irrigation operations is included in this ready-to-work set.

300L trailed watering bowser with electric Zero Emission pumping system and automatic hose reel for on-site tow.

For mobile irrigation tasks, towable autonomous irrigation system for small machinery is available. Tow with any small machinery available like lawn tractor, ATV, UTV, utility vehicle, small tractor, loader or other small vehicles. Achieve higher irrigation efficiency and cut workforce requirements.

Rigid PE plastic water tank on chassis with broad turf wheels and ball coupling for towing in tight spaces. Perfect for both outdoor and indoor use, equipped with automatic hose reel and 12V electrical pumping system for emission-free and quiet operation. The included battery pack allows for emptying more than 10 tankfulls and gives you autonomous work for a full day.

View technical data
  • Customize Your Equipment

  • *

300L Trailed Electric Water Bowser for on-site tow.

Watering, water transport, and firefighting systems that are reliable and ready to use.

Foresteel FTW-300E Watering Trailer Benefits

Technical data

Tank capacity

300 L

Dimensions

L 2020 m x W 1190 mm x H 1480 mm

Weight (empty)

125 kg

Weight (full)

425 kg

Construction

Durable UV resistant PE plastic tank on galvanized steel frame with forklift pockets

Pumping system

12V electrical pump, 20 l/min max capacity, integrated filter.
Integrated 75Ah battery pack with charge indicator and standalone smart charger included.
Flow output with 20m 1/2” hose ~10 l/min

Work time

Work time approx 3.5 hours with full battery.
Equals ~4000 liters or 13 tankfulls.

Hose

20m 1/2" hose on automatic reel in elevated position for comfortable usage

Charging

Integrated charge level indicator with charger plug on battery pack.
Standalone 220V fully automatic charger included with the delivery.
Charge time: charge overnight

Chassis

Modular steel chassis with bolted axle and drawbar. D50 mm ball coupling. Wheeled parking foot. Wide turf tires.
* Chassis is removable and the unit can be converted into an watering platform to be transported with any trailer or pickup truck

Delivery information

Delivered to door with tail lift truck. Packaged on pallet, with drawbar and wheels unassembled for transport. Easy assembly. Instructions included. No unloading equipment needed by customer for receipt (Unless requested for delivery fully assembled)

Standard equipment

PE plastic tank on steel underframe with forklift pockets
Details
PE plastic tank on steel underframe with forklift pockets
PE plastic tank on steel underframe with forklift pockets
20m 1/2″ watering hose on automatic reel with adjustable spray nozzle
Details
20m 1/2″ watering hose on automatic reel with adjustable spray nozzle
20m 1/2" watering hose on automatic reel with adjustable spray nozzle
Autonomous electric pumping system, incl. battery and charger
Details
Autonomous electric pumping system, incl. battery and charger
Fully autonomous zero-emission irrigation with electric pump for noiseless and emissionless action. Integrated battery pack gives more than 3h constant work time that allows to empty more than 3000 liters of volume. 12V 20l/min, automatic start-stop system to maximize battery efficiency.
Automatic start-stop system. Pump switches off when not in use.
Details
Automatic start-stop system. Pump switches off when not in use.
Automatic start-stop system. Pump switches off when not in use.
Watering can tap – fill watering can from free flow
Details
Watering can tap – fill watering can from free flow
Watering can tap – fill watering can from free flow. No need to run the pump.
Including 75+ Ah battery, battery box
Details
Including 75+ Ah battery, battery box
Including 75+ Ah battery, battery box
200mm diameter top hatch
Details
200mm diameter top hatch
200mm diameter top dome for easy cleaning and mixing
Trailer chassis for 300L version
Details
Trailer chassis for 300L version
Trailer chassis for 300L version with 20x10x8" turf wheels, parking jack, 50mm ball coupling.

Easy and simple!

FTW-300 Trailed Watering Bowser can help you with your daily tasks and solve several problems.

Seasonal irrigation tasks take a lot of time and resources. We have extensive experience of producing efficient mobile irrigation, watering and liquid transport systems.

We have worked closely with customers and redesigned the mobile watering solution so it can be easily lifted, transported and used by anyone with basic knowledge. Simplified on-tank instructions make using the system easy and intuitive. Carefully chosen reliable components make it one of the most reliable and trustworthy options available on the market.
Here’s how we can help:

Problem

The solution offered by Foresteel

In one set, a compact ready-to-use water transportation, irrigation, and firefighting trailer. Tanks that are durable and rigid, as well as pumping systems that are optimized, are all assembled on a solid steel chassis with wide wheels and adjustable tow coupling. Grounds maintenance and horticultural enterprises, park maintenance managers, farms and municipality managers can all benefit from this irrigation solution.
Foresteel mobile water bowsers are the go-to solution for groundcare and horticulture companies, farms, university campuses, campsites, vineyards, park maintenance and public spaces managers working where time is valuable and an external water supply is not available.
